The New 6500 CPU's by Jim Butterfield Compute! September 1983 | Reproduced with Jim Butterfield's permission April 20, 2002: To see the original source document go to the C= Gallery tab, Magazine Articles, Misc. Also, you can see the original Commodore / MOS / CSG 6500 / 6502 and 6509 processor manual on our C= Gallery, Manuals page.
Quick And Easy the 6502 burst onto the microprocessor scene in 1976. It was remarkably inexpensive and seemed to have a very simple internal structure. The architecture was closest to Motorola's 6800 microprocessor series, and many users suspected that the 6502 was a cheap imitation. This proved to be untrue: the 6502 had special features which made it a landmark in microprocessor design.
The technique which gave the 6502 speed is called "pipelining." It means that information rolls into the processor as if it were on a conveyer belt. Before the last piece of information is digested, the next one is coming in. For the first time, the microprocessor didn't need to "stop and think": new information was rolling in as the old was being digested. The result: no wasted memory cycles, and amazing speed.
The small number of registers within the 6502 seemed to be a limitation. It proved not to be: registers could be loaded and used so quickly that the small number seldom gave problems. In addition, page zero of memory could be used to hold 16-bit pointers for "indirect addressing" –in a sense, this provided an extra 128 registers for the programmer's use.
The 6510 The 6510 is a 6502, except that addresses 0000 and 0001 have special functions. There's an.input/ output port built into the chip: eight pins marked Po to P7 are available on the microprocessor chip itself. Address 0000 is used as the direction register of the 1/0 port, and 0001 is the port itself. Otherwise, the 6510 is identical to a 6502.
What does this mean in the Commodore 64? First of all, locations 0000 and 0001 are no longer; RAM. PET uses these locations to hold the USR jump; on the Commodore 64, this jump has been moved to address hex 0310 (784 decimal}. Second, you may use address 0001 to test J and control some of the 64's activities. Refer to the memory map in COMPUTE!, October 1982, for details. For example, you can sense if the cassette tape switch is down by checking PEEK(l) AND 16. The three lowest-order bits are used for switching out ROM and switching in RAM. Don't ever do this from BASIC, and use prudence if you do it from machine language. More on these bits in a moment.
A little more information on memory control from address 0001: bit 0, mask 1, controls the BASIC ROM in addresses AOOO-BFFF. Switch this bit to zero and the BASIC ROM is gone: in its place is RAM. Now you can write your own language. Bit 1, mask 2, controls the Kernal ROM in addresses EOOO-FFFF. Switch this bit to zero and the Kernal is gone; be very careful, since you've just 1 switched away all of the programs that support J interrupts, keyboard, screen, and so on. If you switch off both bits 0 and 1, you will get a 64K RAM machine: the I/O block will be switched out, too.
The 6509 The 6509, too, is a 6502 with a change to addresses 0000 and 0001. In this case, the changes are more profound: they cause a switch to a new memory bank. The 6509 is expected to be used in the newest CBM products: the PET II {PI28) and the CBM II (B and BX series).
Both addresses 0000 and 0001 are used to provide access to memory beyond the normal 64K limitation. These addresses are used to. "bank switch" to one of 16 memory banks, each of which is 64K in size. Thus, the 6509 can access over one million memory locations.
If we place a value of zero to 15 in address 0001, we will influence only one kind of address indirect, indexed. So if we code LOA #$01:STA $01 we are selecting bank one for indirect addressing. Now, if we code LOA ($FO), y we will perform the following steps: go to addresses OOFO and 00Fl in the current bank and get the new address stored there; add the contents of the y register to this new address; and finally, load the A register with the contents of the resulting address, from bank one. Indirect addressing is generally used to obtain or store data; the extra capability provided.
With address 0001 allows us to obtain or store a very large amount of data. Address 0000 changes the bank from which we obtain instructions. If we code LOA #$01:ST A00 we will immediately start executing instructions from bank one. This is tricky: we have not umped, so we will start executing from precisely he same address we left in the other bank. We must carefully write "synchronized" programs so that when we leave one bank, there will be a program in exactly the right place in the new bank to allow processing to continue. It's a good trick, but can be done.
The new chips are still 6500 style. They use the same instructions in exactly the same way but they open up new possibilities, and we'll need learn how to cope with them.
____________________________ The following is a partial list of products that the 6500 based cpu's have (and are) used in:
Apple IIc IIgs Nintendo Super Nintendo Gameboy? Rockwell Modems General Instruments Set Top Boxes Micronas Digital TV Chip Sets Micronas Dashboard Controllers Pace Makers Click HERE for a much more complete list of MOS 6502 based hardware.
Click HERE for a 8501CPU list.
|
If the same chip goes into a
6502 and, say, a 6504, why not take the fully-featured processor every time? The
answer is this: if you don't need the extra pins, you can save money by going
for the small one. Process controllers often need very little memory; savings in
board space and a lesser umber of connections can be quite worthwhile.
